HANDLEBAR UNIT
Name Torque in Nm
Handlebar to headstock fixing nut 52.5
Throttle control fixing screw 3.5
Opening throttle control transmission fixing nut 3.5
Mirror fixing screw 25
ELECTRICAL SYSTEM UNIT
Name Torque in Nm
Horn fixing screw 10
Voltage regulator fixing screw 10
Control unit fixing screw 10
Coil fixing screw 5
Start-up relay fixing screw 10
LIGHTS AND INSTRUMENT PANEL UNIT
Name Torque in Nm
Front headlamp fixing screw 3
Rear light fixing screw 6
Rear light fixing screw 3
Nut fixing license plate lamp 3
Instrument panel fixing screw 3
FUEL TANK UNIT
Name
Torque in Nm
Fuel tank to chassis lateral fixing screw 10
Fuel tank to chassis rear fixing screw 10
SADDLE UNIT
Name
Torque in Nm
Saddle plate fixing nut 10
BODYWORK UNIT
Name
Torque in Nm
Helmet compartment fixing screw 6
Helmet compartment fixing screw 3
Passenger handgrip profiles fixing screw 3
Passenger handgrip fixing screw 20.5
Battery cover fixing screw 6
Front head fixing screw 6
Front head fixing screw 3
Rear head fixing screw 3
Front wheel well fixing screw 6
Front wheel well fixing screw 3
Front mudguard fixing screw 6
Mats kit fixing screw 6
Mats kit fixing screw 3
Footrest fixing screw 6
Shield upper lock fixing screw 6
Lid hinge fixing screw 3
Internal shield fixing screw 6
Internal shield fixing screw 3
Under-footrest fixing screw 6
Central lock fixing screw 3
Right side lock to right passenger footrest fixing screw 3
Left side lock to left passenger footrest fixing screw 3
Right fairing right passenger footrest fixing screw 6
Left fairing left passenger footrest fixing screw 6
Right and left fairings to headlamp support fixing screw 3
Pre-assembled tail section to vehicle fixing screw 6
Inspection cover fixing screw 6
Mudflap fixing screw 6
SPORTCITY ONE 125 Characteristics
CHAR - 15
