APRILIA SPORTCITY ONE 125 Service Station Manual

Brakes
BRAKES
Specification Desc./Quantity
Front brake Ø 220-mm disc brake with hydraulic transmission
Rear brake Ø 140-mm drum brake with mechanic transmission
Wheels and tyres
WHEEL RIM
Specification Desc./Quantity
Rims alloy
Front wheel 3.00 x 14"
Rear wheel 3.50 x 14"
TYRES
Specification Desc./Quantity
Front tyre 120/70 - 14" 52K Tubeless
Rear tyre 120/70 - 14" 52K Tubeless
Front tyre standard inflation pressure 180 kPa (1.8 bar)
Rear tyre standard inflation pressure 200 kPa (2.0 bar)
Front tyre standard inflation pressure with passenger 190 kPa (1.9 bar)
Rear tyre standard inflation pressure with passenger 220 kPa (2.2 bar)
Tightening Torques
FRAME ASSEMBLY
Name
Torque in Nm
License plate holder support fixing screw 10
ENGINE LINK ROD UNIT
Name
Torque in Nm
Nut fixing the chassis-side swinging arm and the engine-side
swinging arm
42.5
Engine-side swinging arm retaining nut 42.5
Chassis-side swinging arm retaining nut 52.5
Buffer plate to chassis retaining nut 40
STAND UNIT
Name
Torque in Nm
Central stand to chassis fixing screw 42.5
FRONT SUSPENSION
Name
Torque in Nm
Stems-plate fixing screw 40
Stems-sleeve fixing screw 30
Wheel pin hub fixing screw 10
Upper ring nut 37.5
Lower ring nut 13
REAR SUSPENSION UNIT
Name
Torque in Nm
Nut fixing shock absorber bracket on engine 22.5
Upper part of the shock absorber retaining nut 22.5
Lower part of the shock absorber retaining nut 42.5
SPORTCITY ONE 125 Characteristics
CHAR - 13

APRILIA SPORTCITY ONE 125 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70 - 14
Rear Tire	120/70 - 14
Transmission	Automatic
Fuel Capacity	7 liters
