33.12
Removing needle rol
ler bearing for input bevel
pin
io
n
•
Split the needle r
oller beari
ng cage open.
•
Heat the housing to 130
°
C..
•
Pull out the needle roller bearing outer race w
ith
internal pu
ller,
BMW No.
00 8 573
, and counter-
sup
por
t,
BMW No.
00
8 570
.
Installing n
eedle roller b
earing
for i
nput be
vel
pin
io
n
•
Heat the needle r
oller bearing seat
to 100
°
C.
•
Press in
needle roller bearing
using drift o
r the in-
put bevel pinio
n.
LT330020
LT
33
.0
06
00 8 570
00 8 573
RT330060
280
282
