46.16
[RT] Removing and installing
rear
fairing
•
Remove dualseat.
•
Remove small
side sectio
ns of fair
ing.
•
Remove r
ear light.
•
Remove luggage rack and case holder.
•
Remov
e rear
fairings (
1) and
(2).
•
Install i
n the reverse ord
er of work.
L
Not
e:
When installing, no
te right and left
rubber
buffers (3).
3
1
2
RT460331
358
360
