33.17
•
Using puller, BMW No. 00 7 500, pull taper roller
bearing off crown wheel.
•
Pull out the outer race using internal puller,
BMW No. 00 8 560.
Installing crown wheel
•
Heat the housing to 80 °C.
•
Insert the outer race in the bearing seat with drift,
BMW No.331880, and handle,
BMW No.005500.
•
Check that outer race is correctly fitted by strik-
ing gently.
L Note:
If new parts are installed (e.g. taper roller bearing),
check tooth backlash and adjust if necessary.
•
Place the existing spacer ring (1) on the crown
wheel.
•
Heat taper roller bearing (2) to 80 °C and push it
on.
•
Install crown wheel (3).
•
Heat deep-groove ball bearing (4) to 80 °C and
place it in position.
00 7 500
LT330140
00 8 560
LT330150
00 5 500
33 1 880
LT330160
1
2
3
4
RT330170
