46.18
[RT] Removing and installing
lower
rear section
e
Caution:
Sw
itch
off
igni
tio
n.
Disconnect ground (earth) lead from
battery.
Insulate ground (earth) le
ad.
•
Remove dualseat.
•
Remove small
side sectio
ns of fair
ing.
•
Remove r
ear light.
•
Remove luggage rack and case holder.
•
Remo
ve
rear
tr
im p
ane
l.
•
Remo
ve lower
rear sec
tion
.
•
Install i
n the reverse ord
er of work.
2x
2x
2x
2x
RT460350
360
362
