46.28
[RS] Removing and installing
adjustable windshield
•
Remove w
indshield.
•
Remove side sections of fairing
.
•
Remove inner fairing panel.
•
Turn adjusting shaft (1) counterclockwise to
unfasten.
•
Det
ach i
nstr
um
ent
clus
te
r.
•
Detach top section of fairing
.
•
Remove headlight.
•
Remove brack
et (2) for wi
ndshie
ld.
•
Install i
n the reverse ord
er of work.
1
2
RS460090
370
372
