00.25
Renewing fuel filter
(Inspektion II
I)
•
Remove dualseat.
•
[RS/RT]
Take off side sections of fairing.
•
[RS]
Detach cock
pit inner panel (1
) at fuel tank.
•
[GS]
Remove
rig
ht s
ide fa
ir
ing
.
•
[R]
Remove fuel tank c
over.
•
[RT]
Detach storage comp
artment
•
Unfasten fuel tank mount (2)
•
Seal off fuel feed and return line (3) wi
th hose clip,
BMW No
. 13 3 01
0
, loosen and pul
l off.
•
Remove vent pipes (4)
.
•
Remove fuel pump connector (5).
•
Lift off fuel tank.
RS
1
5
3
4
2
13 3 010
RS160010
32
34
