4.4.4 Connect a Single Limb Circuit with Active Exhalation Valve
1 Connect the patient circuit to the
patient air outlet of the ventilator.
2 Connect the control pressure tubing to
the exhalation valve, and to the exhalation
valve control pressure outlet of the Vivo 65.
3 Connect the other end of the patient circuit to an HME or patient interface.
4.5 Inspecting the Vivo 65 before Use
Inspection of Device
• Check that there is no visible damage.
• Check that the surface is clean.
Inspection of Cables
• Check that all cables are recommended by Breas.
• Check that the cables are undamaged.
• Check that the cables are properly connected.
Inspection of Placement
• The Vivo 65 shall be placed on solid flat surface below the patient level. (See 4.2 Placing
the Vivo 65, page 32.)
• Make sure that nothing can block the air inlet at the side.
Preparing the Vivo 65 for Use 39
Doc. 006150 M-1 User manual
