Be careful when handling the trolley with the ventilator mounted, in order to avoid any risk
of the trolley falling. The trolley can be tipped 10° and return to vertical position, when
loaded in accordance with the weight specifications below.
WARNING!
The maximum total weight of the trolley and added accessories is 37 kg (82 lbs). (Trolley
base weight = 12 kg (26 lbs), maximum externally added load = 25 kg (55 lbs).)
• The maximum load of the trolley basket is 0.9 kg (2 lbs).
• The maximum load of the IV-pole is 3 kg (6.5 lbs).
• The maximum load of the trolley rail is 9 kg (20 lbs).
• The maximum load of the E-cylinder holder is 7.9 kg (17.5 lbs).
No maintenance is required.
5.8.8 Using the Vivo 65 with the Protective Cover
The protective cover is intended for additional protection of the Vivo 65 during transporta-
tion, and in hospital, institutional and home care environments. It can be used while the
Vivo 65 is operating, for example mounted on a wheelchair, in a personal vehicle, or carried
by hand.
Do not use the Vivo 65 in the protective cover while positioned in a warm place, such as
direct sunlight or close to a radiator.
The protective cover has the following functions:
86 How to Use the Vivo 65
User manual
Doc. 006150 M-1
