Briggs & Stratton MS-1055 User Manual

14
7
TURBOCHARGER
REMOVE TURBOCHARGER
1. Remove the muffler or exhaust pipe from the
turbocharger.
2. Lift tab on tie strap and remove tie strap. Then
remove crankcase breather tube at air intake tube.
Fig. 13 – Remove Clamp
TIE
STRAP
TAB
3. Disconnect the air intake tube at the turbocharger.
4. Disconnect the air intake tube from the air intake
pipe.
AIR INTAKE
TUBE
Fig. 14 – Disconnecting Air Intake Tube
5. Remove the two nuts, and remove the air intake
pipe from turbocharger.
Fig. 15 – Removing Air Intake Pipe
AIR INTAKE PIPE
6. Remove the coolant inlet hose from coolant inlet
line.
Fig. 16 – Removing Coolant Hose
COOLANT HOSE
