Brother BC800 - Needle Plate B Assembly Removal; Needle Plate B ASSY Disassembly

2 - 4
Main parts
Main unit
3 Needle plate B assembly removal
1. Remove the needle plate cover 1.
2. Remove the needle plate B assembly 2.
1
2
3-1 Needle plate B ASSY disassembly
1. Remove the cutter cover 2 from the needle plate B assembly 1.
2. Remove the spring plate 3 from the cutter cover 2, and then remove the
NT lower thread cutter 4.
3. Remove the 2 slide button hooks 5, and then remove the slide button 6.
21 5
6543
