3 - 11
Main parts
Main unit
Assembly
14
FC jack attachment
1.
Insert the FC jack assembly
1
from the inside of the arm bed
cover
assembly.
2.
Attach the jack nut
2
from the outside of th
e arm bed cover assembly.
*Key point
•
Pass the lead wire of the FC jack assembly
1
through the
rear of the main motor.
21
15
Inlet assembly attachment
1.
Attach the inlet assemb
ly
1
with the screw
1
.
1
Torque
0.78 – 1.18 N
·
m
1
1
T
aptite, Bind B
M4X10
Color; Gold
61
63
