Carrier i-Vu CCN Pro 4.2 User Manual

Monitor and control equipment
i-Vu CCN Pro 4.2 43
You can monitor and control equipment from:
• The equipment's points shown under Properties (page 31)
• The equipment graphic (page 28) (if the device has an equipment graphic)
• The equipment's CCN tables (page 43)
If a point's value is editable, changing the value sends the new value only to the device.
If the point has a Force checkbox, you can force the value to a new value that you specify. The new value is
sent to the device. Forced values are indicated in the graphics by a dashed yellow line.
To view an equipment's CCN tables
1 In the navigation tree, select the equipment.
2 Click
next to the equipment to expand it.
3 Select the table you want to view.
To force a CCN point value
You can force certain editable point values to a specified setting:
• In the equipment's tables - to see tables, click next to the equipment
• From a graphic - hold down Ctrl key on your keyboard and, using your mouse, click on the point value on
the graphic. A
Properties dialog will be displayed.
Forced values are indicated by a dashed yellow line on graphics.
1 Select the Force checkbox.
2 Type the value you want to send to the device.
3 Click OK or Apply.
Monitor and control equipment
