FINAL DRAFT - CISCO CONFIDENTIAL
9-19
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
9.7.12 ED-NE-GEN
Command ED-NE-GEN
Edit general parameters of the ONS 15216 EDFA2. Edits ONS 15216 EDFA2’s sid (source
identifier)/tid (target identifier), IP address, IP mask, and IP address of the default router. The
ONS 15216 EDFA2 needs to be manually rebooted for the changes to take effect. (Use the INIT-SYS
command to manually reboot after changing parameters.) Also edits the boot table content: to return to
the TL1 shell from the ASH shell, use the ASH command shell type modify tl1 (step 3. in “Log In via
RS-232 (EIA/TIA-232) Port Using HyperTerminal” section on page 8-1).
Syntax
ED-NE-GEN:[<tid>]::<ctag>:::[NAME=<name>],[IPADDR=<ipaddr>],[IPMASK=<ipmask>],[DEFRTR=<def
rtr>],[BOOTRECORDTYPE1=<bootrectype1>],[BOOTFILENAME1=<bootfilename1>],[BOOTIPADDR1=<booti
paddr1>],[BOOTRECORDTYPE2=<bootrectype2>],[BOOTFILENAME2=<bootfilename2>],[BOOTIPADDR2=<bo
otipaddr2>],[CLI=<cli>];
Example 9-14 ED-NE-GEN Command
Amp01:ONS15216 EDFA2> ED-NE-GEN:Amp01::123:::NAME=Amp01,IPADDR=192.167.3.4,IPMASK=255.255.
255.0,DEFRTR=192.167.3.20,BOOTRECORDTYPE2=TFTP,BOOTFILENAME2=15216EdfaSw_1.4.0,BOOTIPADDR2
=192.168.3.4,CLI=ASH;
pwrbusmode Power bus mode. Possible values are:
SIMPLEX Simplex mode. Requires power only to bus A. Sets
cerent15216EdfaPowerBusMode to simplex.
DUPLEX Duplex mode (default). Requires power to both bus A and bus
B. Sets cerent15216EdfaPowerBusMode to duplex.
Table 9-18 ED-ENV Syntax Description (continued)
Parameter Syntax Description
Table 9-19 ED-NE-GEN Syntax Description
Parameter Syntax Description
name string System’s sid/tid name (sysName).
ipaddr string IP address of the system
(cerent15216EdfaSromIpMgmtEnetAddress).
ipmask string Subnet mask of the system
(cerent15216EdfaSromIpMgmtEnetSubNetMask).
defrtr string IP address of the default router
(cerent15216EdfaSromIpMgmtDefaultRouterAddress).
bootrectype1 Boot record type (cerent15216EdfaBootType for first entry).
Possible values are:
FLASH Boot from flash.
TFTP Boot through TFTP.
