Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
Table 9-27 REPT ALM EQPT Syntax Description
Parameter Syntax Description
almcde The alarm severity code for the TL1 message. Possible values
are:
*C Critical alarm.
** Major alarm.
* Minor alarm.
A No alarm. Occurs only when ntfncde is NA.
atag 0 - 999 An integer between 0 and 999 used as a sequence number in
autonomous messages .
aid
Always EQPT.
EQPT General parameters of the ONS 15216 EDFA2 (not directly
affecting optical signal or power bus).
conddescr Detailed text description of the event. The conddescr is 1 to 64
characters of ASCII text. See condtype below.
condtype Condition type identifies the type of alarm (maps to
cerent15216EdfaLogEventID). Possible condtype and
corresponding conddescr (in quotes) are:
CTMP “Case Temperature Out of Range” alarm
(cerent15216EdfaAlarmCtmp).
LCRNT1 “Excessive Pump1 Current” alarm
(cerent15216EdfaAlarmLcrnt1).
LCRNT2 “Excessive Pump2 Current” alarm
(cerent15216EdfaAlarmLcrnt2).
LTMP1 “Excessive Pump1 Temperature” alarm
(cerent15216EdfaAlarmLtmp1).
LTMP2 “Excessive Pump2 Temperature” alarm
(cerent15216EdfaAlarmLtmp2).
date yyyy-mm-dd Date of origination of TL1 message.
ntfncde Notification code (maps to cerent15216EdfaAlarmPriority).
Possible values are:
CR Critical alarm.
MJ Major alarm.
MN Minor alarm.
CL Cleared alarm.
NA No alarm.
ocrdat m-d Date (month-day) of the event occurrence (derived from
cerent15216EdfaDateAndTimeString).
ocrtm h-m-s Time (hour-minute-second) of the event occurrence (derived
from cerent15216EdfaDateAndTimeString).
sid string Source identifier uniquely identifies the source of a TL1
autonomous command.
