Page #80 background image
FINAL DRAFT - CISCO CONFIDENTIAL
5-18
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 5 SNMP MIB Installation and Configuration
Tables and Groups
5.4.4 OverallControl Table
The cerent15216EdfaOverallControl table allows the user to display and configure overall gain and
pre-attenuation. Table 5-9 describes cerent15216EdfaOverallControl variables.
5.4.5 PumpStatusEntry Table
The cerent15216EdfaPumpStatusEntry table is used to display optical amplification module data.
Table 5-10 displays information regarding the cerent15216EdfaPumpStatusEntry table variables.
Table 5-9 cerent15216EdfaOverallControl Variable Descriptions
Variable Syntax
Maximum
Access Description
cerent15216EdfaConst
GainOverallGain
Integer (130 to
220)
Read-write The overall gain (*10 dB) that is used when
the control mode in the PumpCfgEntry table
is set to constGainTempComp.
This variable is irrelevant in
constOutputPower, constCurrent, and
constPower modes.
cerent15216EdfaVariab
leGainPreAttenuation
Integer (10 to
100)
Read-write The pre-attenuation (*10 dB) that is used
when the control mode in the PumpCfgEntry
table is set to constOutputPower,
constCurrent, or constPower.
This variable is irrelevant in
constGainTempComp mode.
Table 5-10 cerent15216EdfaPumpStatusEntry Variable Descriptions
Variable Syntax
Maximum
Access Description
cerent15216EdfaPumpStatusPumpNum cerent15216Ed
faPumpNumber
Read-only Laser pump number
cerent15216EdfaPumpStatusLaserChipTemp Integer (–9999
to 9999)
Read-only Laser chip
temperature (*10
°C)
cerent15216EdfaPumpStatusLaserChipTemp
Setpoint
Integer (0 to
999)
Read-only Laser chip
temperature setpoint
(*10°C)
cerent15216EdfaPumpStatusLaserTECCurre
nt
Integer (0 to
99999)
Read-only Laser TEC current
(mA)
cerent15216EdfaPumpStatusLaserPower Integer (0 to
99999)
Read-only Laser power (*100
mW)
cerent15216EdfaPumpStatusLaserCurrent Integer (0 to
999999)
Read-only Laser current (*100
mA)
cerent15216EdfaPumpStatusAmbientTemp Integer (–9999
to 9999)
Read-only Ambient temperature
(*100
°C)
