Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
Syntax RTRV-ALM-ALL:[<tid>]::<ctag>::[<ntfcncde>],[<condtype>],[<srveff>][,,,,,];
<sid> <date> <time>
M <ctag> COMPLD
"<aid>,<ccm>:<ntfcncde>,<condtype>,<srveff>,<ocrdat>,<ocrtm>,,:<conddescr>"
;
Example 9-25 RTRV-ALM-ALL Command and Response
Amp01:ONS15216 EDFA2> RTRV-ALM-ALL:Amp01::229::MN,LCRNT1,NSA,,;
Amp01 2002-06-20 14:30:00
M 229 COMPLD
"1,DWDM:MJ,LOS,SA,6-20,14-25-30,,:\"Loss Of Signal\""
"EQPT,EQPT:MN,LCRNT1,NSA,6-20,14-25-30,,:\"Excessive Pump1 Current\""
;
Table 9-30 RTRV-ALM-ALL Syntax Description
Parameter Syntax Description
aid Possible values are:
1 Directly affecting the optical signal
EQPT General parameters of the ONS 15216 EDFA2 (not directly
affecting optical signal or power bus)
conddescr Detailed text description of the event. The conddescr is 1 to 64
characters of ASCII text. See condtype below
condtype
(ccm)
Condition type identifies the type of alarm (maps to
cerent15216EdfaLogEventID). Possible condtype and
corresponding conddescr (in quotes) are:
LOS
(DWDM)
“Loss of Signal” (input power) alarm
(cerent15216EdfaAlarmLpin).
GAIN
(DWDM)
“Gain Out of Range” alarm (cerent15216EdfaAlarmGain).
LPOUT
(DWDM)
“Loss of Output Power” alarm (cerent15216EdfaAlarmLpout).
CTMP
(EQPT)
“Case Temperature Out of Range” alarm
(cerent15216EdfaAlarmCtmp).
LCRNT1
(EQPT)
“Excessive Pump1 Current” alarm
(cerent15216EdfaAlarmLcrnt1).
LCRNT2
(EQPT)
“Excessive Pump2 Current” alarm
(cerent15216EdfaAlarmLcrnt2).
LTMP1
(EQPT)
“Excessive Pump1 Temperature” alarm
(cerent15216EdfaAlarmLtmp1).
LTMP2
(EQPT)
“Excessive Pump2 Temperature” alarm
(cerent15216EdfaAlarmLtmp2).
date yyyy-mm-dd Date of origination of TL1 message.
