Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
Table 9-28 REPT EVT DWDM / REPT EVT ENV / REPT EVT EQPT Syntax Description
Parameter Syntax Description
atag 0 - 999 An integer between 0 and 999 used as a sequence number
in autonomous messages .
aid Possible values are:
1 Directly affecting the optical signal.
PWR-A Affecting Power Bus A (or both A and B).
PWR-B Affecting Power Bus B.
EQPT General parameters of the ONS 15216 EDFA2 (not
directly affecting optical signal or power bus).
conddescr Detailed text description of the event. The conddescr is 1
to 64 characters of ASCII text. See condtype below.
condtype
(ccm)
Condition type identifies the type of event (maps to
cerent15216EdfaLogEventID). Possible condtype and
corresponding conddescr (in quotes) are:
CTRLMODE1
(DWDM)
“Pump1 Control Mode Changed”
(cerent15216EdfaControlMode for
cerent15216EdfaPumpCfgPumpNumber=1).
CTRLMODE2
(DWDM)
“Pump2 Control Mode Changed”
(cerent15216EdfaControlMode for
cerent15216EdfaPumpCfgPumpNumber=2).
GAINCHGD
(DWDM)
“Overall Gain Changed”
(cerent15216EdfaConstGainOverallGain).
LOSHYSTCHGD
(DWDM)
“LOS (loss of signal) Hysteresis Changed”
(cerent15216EdfaLOSHysteresis).
LOSTHCHGD
(DWDM)
“LOS (loss of signal) Threshold Changed”
(cerent15216EdfaLOSThreshold).
LPOUTCHGD
(DWDM)
“Loss of Output Power Setpoint Changed”
(cerent15216EdfaLpoutSetpoint).
LPOUTDEVCHGD
(DWDM)
“Lpout (loss of output power) Deviation Changed”
(cerent15216EdfaLpoutDeviation).
LPOUTHYSTCHGD
(DWDM)
“Lpout (loss of output power) Hysteresis Changed”
(cerent15216EdfaLpoutHysteresis).
PREATTCHGD
(DWDM)
“Pre-attenuation Changed”
(cerent15216EdfaVariableGainPreAttenuation).
PWRBUSMAXCHGD
(EVN)
“Power Bus Max (voltage) Changed”
(cerent15216EdfaPowerBusDCVoltageMax).
PWRBUSMINCHGD
(EVN)
“Power Bus Min (voltage) Changed”
(cerent15216EdfaPowerBusDCVoltageMin).
PWRBUSMODE
(EVN)
“Power Bus Mode Changed”
(cerent15216EdfaPowerBusMode).
MAXCTMPCHGD
(EQPT)
“Max Case Temperature Changed”
(cerent15216EdfaCtmpMax).
