Cisco 15216 EDFA2 User Manual

FINAL DRAFT - CISCO CONFIDENTIAL
9-59
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
9.7.42 RTRV-TOD
Command RTRV-TOD
Retrieves the date and time of the ONS 15216 EDFA2.
Syntax
RTRV-TOD:[<tid>]::<ctag>[::];
<sid> <date> <time>
M <ctag> COMPLD
"<tmody>,<tmtype>,<tmsrcdv>,<tmsrcst>"
;
Example 9-45 RTRV-TOD Command and Response
Amp01:ONS15216 EDFA2> RTRV-TOD:Amp01::123;
Amp01 2002-06-20 14:30:00
M 123 COMPLD
"2002,06,20,14,30,00,000,UTC,GPS,IS-ACT"
;
Table 9-49 RTRV-TOD Syntax Description
Parameter Syntax Description
date yyyy-mm-dd Date of origination of TL1 message.
time hh:mm:ss Time of origination of TL1 message.
tmody
format:
YYYY
MM
DD
HH
MM
SS
sss
01 - 12
01 - 31
00 - 23
00 - 59
00 - 59
000
Time of day of the format: YYYY,MM,DD,HH,MM,SS,sss
Current calendar year
Month
Day
Hour
Minutes
Seconds
Sub-seconds, currently fixed at 000.
tmtype UTC Type of time, currently fixed at universal coordinated time
(UTC), which is the same as Greenwich Mean Time (GMT).
tmsrcdv GPS Time source deviation, currently fixed at GPS.
tmsrcst IS-ACT State of the time source, of the format
<primaryState>-<secondaryState> (per Telcordia
GR-1093-CORE), currently fixed at IS-ACT (In_Service,
Active).
