Cisco 15216 EDFA2 User Manual

FINAL DRAFT - CISCO CONFIDENTIAL
2-3
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 2 Technical Specifications
Electrical Specifications
2.2 Electrical Specifications
The ONS 15216 EDFA2 uses a power supply that meets the electrical specifications listed in Table 2-3.
16 –8.0 –9.0 –10.0 –11.0 –12.0 –13.0 –14.0 –15.0 –16.0 –17.0
17 –8.3 –9.3 –10.3 –11.3 –12.3 –13.3 –14.3 –15.3 –16.3 –17.3
18– –8.6 –9.6 –10.6 –11.6 –12.6 –13.6 –14.6 –15.6 –16.6 –17.6
19 –8.8 –9.8 –10.8 –11.8 –12.8 –13.8 –14.8 –15.8 –16.8 –17.8
20 –9.0 –10.0 –11.0 –12.0 –13.0 –14.0 –15.0 –16.0 –17.0 –18.0
21 –9.2 –10.2 –11.2 –12.2 –13.2 –14.2 –15.2 –16.2 –17.2 –18.2
22 –9.4 –10.4 –11.4 –12.4 –13.4 –14.4 –15.4 –16.4 –17.4 –18.4
23 –9.6 –10.6 –11.6 –12.6 –13.6 –14.6 –15.6 –16.6 –17.6 –18.6
24 –9.8 –10.8 –11.8 –12.8 –13.8 –14.8 –15.8 –16.8 –17.8 –18.8
25 –10.0 –11.0 –12.0 –13.0 –14.0 –15.0 –16.0 –17.0 –18.0 –19.0
26 –10.1 –11.1 –12.1 –13.1 –14.1 –15.1 –16.1 –17.1 –18.1 –19.1
27 –10.3 –11.3 –12.3 –13.3 –14.3 –15.3 –16.3 –17.3 –18.3 –19.3
28 –10.5 –11.5 –12.5 –13.5 –14.5 –15.5 –16.5 –17.5 –18.5 –19.5
29 –10.6 –11.6 –12.6 –13.6 –14.6 –15.6 –16.6 –17.6 –18.6 –19.6
30 –10.8 –11.8 –12.8 –13.8 –14.8 –15.8 –16.8 –17.8 –18.8 –19.8
31 –10.9 –11.9 –12.9 –13.9 –14.9 –15.9 –16.9 –17.9 –18.9 –19.9
32 –11.1 –12.1 –13.1 –14.1 –15.1 –16.1 –17.1 –18.1 –19.1 –20.1
Table 2-2 Maximum Channel Power (continued)
Composite Input
Power (dBm) 4 3 2 1 0 –1 –2 –3 –4 –5
Corresponding
Max. Gain (dB) 13 14 15 16 17 18 19 20 21 22
Number of
Channels at Full
Loading Maximum per Channel Input Power at Maximum Gain Setting (dBm)
Table 2-3 ONS 15216 EDFA2 Electrical Specifications
Requirement Specification
Input voltage –48 VDC
Maximum power consumption < 25 W at 65
°C end of life
Minimum supply voltage –40 VDC
Minimum turn-on supply voltage –43 VDC
Maximum supply voltage –57 VDC or under
Maximum current 0.52 A
