Cisco 15216 EDFA2 User Manual

FINAL DRAFT - CISCO CONFIDENTIAL
9-37
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
9.7.25 RTRV-ALM-ENV
Command RTRV-ALM-ENV
Generates a report on specific or all active environmental (power bus) alarms.
Syntax
RTRV-ALM-ENV:[<tid>]:<aid>:<ctag>::[<ntfcncde>],[<condtype>];
<sid> <date> <time>
M <ctag> COMPLD
"<aid>,<ccm>:<ntfcncde>,<condtype>,<ocrdat>,<ocrtm>,<conddescr>"
;
Example 9-27 RTRV-ALM-ENV Command and Response
Amp01:ONS15216 EDFA2> RTRV-ALM-ENV:Amp01:ALL:229::MN,PWRBUSA;
Amp01 2002-06-20 14:30:00
M 229 COMPLD
"PWR-A,ENV:MN,PWRBUSA,6-20,14-25-30,\"Power Bus A Alarm\""
;
Table 9-32 RTRV-ALM-ENV Syntax Description
Parameter Syntax Description
aid Specifying PWR-A or PWR-B in input has a filter effect on the
response.
PWR-A Affecting Power Bus A (or both A and B).
PWR-B Affecting Power Bus B.
ALL Any or all of the preceding (command input only).
conddescr Detailed text description of the event. The conddescr is 1 to 64
characters of ASCII text. See condtype below.
condtype Condition type identifies the type of alarm (maps to
cerent15216EdfaLogEventID). Possible condtype and
corresponding conddescr (in quotes) are:
PWRBUSA “Power Bus A (voltage) Alarm”
(cerent15216EdfaAlarmPowerBusA).
PWRBUSB “Power Bus B (voltage) Alarm”
(cerent15216EdfaAlarmPowerBusB).
date yyyy-mm-dd Date of origination of TL1 message.
ntfncde Notification code (maps to cerent15216EdfaAlarmPriority).
Possible values are:
CR Critical alarm.
MJ Major alarm.
MN Minor alarm.
CL Cleared alarm.
NA No alarm.
