FINAL DRAFT - CISCO CONFIDENTIAL
5-12
Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 5 SNMP MIB Installation and Configuration
Tables and Groups
5.4.1 CfgGroup Table
The cerent15216EdfaCfgGroup table is used to set or get alarm threshold configuration. The associated
table command provides a summary of all alarm thresholds. See Table 5-6 for variable definitions. For
more information on alarm thresholds, see the “Set Alarm Thresholds” section on page 4-5.
Table 5-6 cerent15216EdfaCfgGroup Variable Descriptions
Variable Syntax
Maximum
Access Description
cerent15216EdfaCfgSaved True Value Read-only Indicates whether the current
configuration has been saved.
cerent15216EdfaLpoutSetp
oint
Integer
(0 to 1000)
Read-only Loss of pump output power set point
for the Lpout alarm (*10 mW).
This is set when the
cerent15216EdfaPumpCfgConstOutP
ower attribute is set for pump 2.
cerent15216EdfaLpoutDevi
ation
Integer
(0 to 1000)
Read-write Amount that the output power must
deviate from the set point to set the
Lpout alarm (*100 dB).
cerent15216EdfaLpoutHyst
eresis
Integer
(0 to 1000)
Read-write Amount that the output power must
move towards the set point before the
Lpout alarm is cleared (*100 dB).
cerent15216EdfaLOSThres
hold
Integer
(–3100 to –1500)
Read-write Loss of signal threshold (*100 dBm).
cerent15216EdfaLOSHyster
esis
Integer
(0 to 1000)
Read-write Amount above
cerent15216EdfaLOSThreshold that
the input signal must rise before the
Lpin alarm is cleared (*100 dB).
cerent15216EdfaCtmpMin Integer
(–10 to 10)
Read-write Minimum allowable case temperature
in degrees Celsius.
cerent15216EdfaCtmpMinH
ysteresis
Integer
(0 to 10)
Read-write Amount above
cerent15216EdfaCtmpMin that the
case temperature must rise before the
Ctmp alarm is cleared in degrees
Celsius.
cerent15216EdfaCtmpMax Integer
(20 to 70)
Read-write Maximum allowable case temperature
in degrees Celsius.
cerent15216EdfaCtmpMax
Hysteresis
Integer
(0 to 10)
Read-write Amount below
cerent15216EdfaCtmpMax that the
case temperature must drop before the
Ctmp alarm is cleared in degrees
Celsius.
