Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
Example 9-43 RTRV-TH-ENV Command and Response
Amp01:ONS15216 EDFA2> RTRV-TH-ENV:Amp01:ALL:123::PWRBUSMIN;
Amp01 2002-07-16 14:24:29
M 123 COMPLD
"PWR-A,ENV:PWRBUSMIN,,,420"
;
9.7.41 RTRV-TH-EQPT
Command RTRV-TH-EQPT
Retrieves general threshold values for the ONS 15216 EDFA2.
Syntax
RTRV-TH-EQPT:[<tid>]:<aid>:<ctag>::[<thresholdtype>][,][,];
<sid> <date> <time>
M <ctag> COMPLD
"<aid>:<thresholdtype>,,,<thresholdvalue>"
;
Table 9-47 RTRV-TH-ENV Syntax Description
Parameter Syntax Description
date yyyy-mm-dd Date of origination of TL1 message.
time hh:mm:ss Time of origination of TL1 message.
aid PWR-A, PWR-B, and ALL have same input effect.
PWR-A Affecting Power Bus A (or both A and B).
PWR-B Affecting Power Bus B.
ALL Any or all of the preceding (command input only).
threshholdtype
and
thresholdvalue
pairs
Type of threshold that is to be retrieved. A null value is
equivalent to ALL. Possible to specify values for one or more
of the following:
PWRBUSMIN Power bus minimum voltage
(cerent15216EdfaPowerBusDCVoltageMin).
thresholdvalue can be between 350 and 700, with default of
400, in units of –10 VDC.
PWRBUSMAX Power bus maximum voltage
(cerent15216EdfaPowerBusDCVoltageMax).
thresholdvalue can be between 350 and 700, with default of
570, in units of –10 VDC.
