Cisco ONS 15216 EDFA2 Operations Guide
78-16033-01
Chapter 9 TL1 Commands
TL1 Commands and Autonomous Messages
9.7.47 SET-TH-EQPT
Command SET-TH-EQPT
Sets general threshold values for the ONS 15216 EDFA2.
Syntax
SET-TH-EQPT:[<tid>]:<aid>:<ctag>::<thresholdtype>,<thresholdvalue>[,,];
Example 9-50 SET-TH-EQPT Command
Amp01:ONS15216 EDFA2> SET-TH-EQPT:Amp01:ALL:123::MAXCTMP,60;
threshholdtype
and
thresholdvalue
pairs
Type of threshold that is to be set. The threshold is set to the
thresholdvalue that follows the comma. Possible to specify
values for one or more of the following:
PWRBUSMIN Power bus minimum voltage
(cerent15216EdfaPowerBusDCVoltageMin).
thresholdvalue can be between 350 and 700, with default of
400, in units of –10 VDC.
The power bus threshold has a 1.0V tolerance and a 1.0V
hysteresis. If the minimum threshold is configured at 400 (-40
VDC), the alarm will not raise until the voltage goes below -39
VDC and will not clear until the voltage goes above -41VDC.
PWRBUSMAX Power bus maximum voltage
(cerent15216EdfaPowerBusDCVoltageMax).
thresholdvalue can be between 350 and 700, with default of
570, in units of –10 VDC.
The power bus threshold has a 1.0V tolerance and a 1.0V
hysteresis. If the maximum threshold is configured at 570 (-57
VDC), the alarm will not raise until the voltage goes above -58
VDC and will not clear until the voltage goes below -56 VDC.
Table 9-53 SET-TH-ENV Syntax Description (continued)
Parameter Syntax Description
Table 9-54 SET-TH-EQPT Syntax Description
Parameter Syntax Description
aid EQPT and ALL have same input effect.
EQPT General parameters of the ONS 15216 EDFA2 (not directly
affecting optical signal or power bus).
ALL Any or all of the preceding (command input only).
