PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Specifies the interface to be configured, and enters interface configuration mode.
interface interface-id
Step 3
Example:
Device(config)# interface
The specified interface must be one of the following:
• A routed port—A physical port that has been configured as a Layer 3 port
by entering the no switchport interface configuration command. You will
gigabitethernet 1/0/1
also need to enable IP PIM sparse-dense-mode on the interface, and join
the interface as a statically connected member to an IGMP static group.
For a configuration example, see Example: Interface Configuration as a
Routed Port, on page 83
• An SVI—A VLAN interface created by using the interface vlan vlan-id
global configuration command. You will also need to enable IP PIM
sparse-dense-mode on the VLAN, join the VLAN as a statically connected
member to an IGMP static group, and then enable IGMP snooping on the
VLAN, the IGMP static group, and physical interface. For a configuration
example, see Example: Interface Configuration as an SVI, on page 83
These interfaces must have IP addresses assigned to them.
Defines a PIM bootstrap message boundary for the PIM domain.ip pim bsr-border
Step 4
Example:
Device(config-if)# ip pim
Enter this command on each interface that connects to other bordering PIM
domains. This command instructs the device to neither send nor receive PIMv2
BSR messages on this interface.
bsr-border
To remove the PIM border, use the no ip pim bsr-border interface
configuration command.
Note
Returns to privileged EXEC mode.end
Example:
Device(config)# end
Step 5
Verifies your entries.show running-config
Step 6
Example:
Device# show running-config
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Step 7
Example:
Device# copy running-config
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
138 OL-29890-01
Configuring PIM
Configuring PIMv2 BSR
