rp-mapping-change--This notification results from a change in the rendezvous point (RP) mapping
information due to either Auto-RP messages or bootstrap router (BSR) messages.
•
invalid-pim-message--This notification results from the following conditions:
•
An invalid (*, G) Join or Prune message is received by the device (for example, when a router
receives a Join or Prune message for which the RP specified in the packet is not the RP for the
multicast group)
•
An invalid PIM register message is received by the device (for example, when a router receives a
register message from a multicast group for which it is not the RP)
Related Topics
Enabling PIM MIB Extensions for IP Multicast, on page 164
Example Enabling PIM MIB Extensions for IP Multicast, on page 166
Benefits of PIM MIB Extensions
PIM MIB extensions:
•
Allow users to identify changes in the multicast topology of their network by detecting changes in the
RP mapping.
•
Provide traps to monitor the PIM protocol on PIM-enabled interfaces.
•
Help users identify routing issues when multicast neighbor adjacencies expire on a multicast interface.
•
Enable users to monitor RP configuration errors (for example, errors due to flapping in dynamic RP
allocation protocols like Auto-RP).
How to Configure PIM MIB Extension for IP Multicast
Enabling PIM MIB Extensions for IP Multicast
Perform this task to enable PIM MIB extensions for IP multicast.
Note
•
The pimInterfaceVersion object was removed from RFC 2934 and, therefore, is no longer supported
in software.
•
The following MIB tables are not supported in Cisco software:
◦
pimIpMRouteTable
◦
pimIpMRouteNextHopTable
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
164 OL-29890-01
Configuring PIM MIB Extension for IP Multicast
Benefits of PIM MIB Extensions
