Page #283 background imageLoading...
Page #283 background image
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
ip mroute [vrf vrf-name] source-address mask { fallback-lookup {global | vrf vrf-name }[ protocol ]
{rpf-address | interface-type interface-number}} [distance]
4.
exit
5.
show running-config
6.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
The source IP address 10.1.1.1 is configured to be
reachable through the interface associated with IP
address 10.2.2.2.
ip mroute [vrf vrf-name] source-address mask {
fallback-lookup {global | vrf vrf-name }[ protocol ]
{rpf-address | interface-type interface-number}} [distance]
Step 3
Example:
Device(configure)# ip mroute 10.1.1.1
255.255.255.255 10.2.2.2
Returns to privileged EXEC mode.exit
Example:
Device(config)# exit
Step 4
(Optional) Verifies your entries.show running-config
Example:
Device# show running-config
Step 5
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
OL-29890-01 261
Configuring IP Multicast Routing
Configuring a Static Multicast Route (mroute) (CLI)
