PurposeCommand or Action
Example:
Device(config)# interface
The specified interface must be one of the following:
• A routed port—A physical port that has been configured as a Layer 3 port
by entering the no switchport interface configuration command. You will
also need to enable IP PIM sparse-dense-mode on the interface, and join
gigabitEthernet1/0/1
the interface as a statically connected member to an IGMP static group.
For a configuration example, see Example: Interface Configuration as a
Routed Port, on page 83
• An SVI—A VLAN interface created by using the interface vlan vlan-id
global configuration command. You will also need to enable IP PIM
sparse-dense-mode on the VLAN, join the VLAN as a statically connected
member to an IGMP static group, and then enable IGMP snooping on the
VLAN, the IGMP static group, and physical interface. For a configuration
example, see Example: Interface Configuration as an SVI, on page 83
These interfaces must have IP addresses assigned to them.
Configures the boundary, specifying the access list you created in Step 2.ip multicast boundary
access-list-number
Step 5
Additional command options include:
Example:
Device(config-if)# ip multicast
•
For access-list-number, the ranges are as follows:
◦ access-list-number 1—99 (IP standard access list)
boundary 99
◦ access-list-number 100—199 ( IP extended access list)
◦ access-list-number 1300—1999 (IP standard access list - expanded
range)
◦ access-list-number 2000—2699 (IP extended access list - expanded
range)
• Word—IP named access list.
• filter-autorp—Filter AutoRP packet contents.
• in—Restrict (s,g) creation when this interface is the RPF.
• out—Restrict interface addition to outgoing list.
Returns to privileged EXEC mode.end
Example:
Device(config-if)# end
Step 6
Verifies your entries.show running-config
Example:
Device# show running-config
Step 7
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
OL-29890-01 267
Configuring IP Multicast Routing
Configuring an IP Multicast Boundary (CLI)
