Cisco Catalyst 3650 User Manual

SUMMARY STEPS
1.
enable
2.
configure terminal
3.
ip multicast-routing [distributed]
4.
Either perform Steps 5 through 7 or perform Steps 6 and 8.
5.
ip pim autorp listener
6.
interface type number
7.
ip pim sparse-mode
8.
ip pim sparse-dense-mode
9.
exit
10.
Repeat Steps 1 through 9 on all PIM interfaces.
11.
ip pim send-rp-announce {interface-type interface-number | ip-address} scope ttl-value [group-list
access-list] [interval seconds] [bidir]
12.
ip pim send-rp-discovery [interface-type interface-number] scope ttl-value [interval seconds]
13.
ip pim rp-announce-filter rp-list access-list group-list access-list
14.
no ip pim dm-fallback
15.
interface type number
16.
ip multicast boundary access-list [filter-autorp]
17.
end
18.
show ip pim autorp
19.
show ip pim rp [mapping] [rp-address]
20.
show ip igmp groups [group-name | group-address| interface-type interface-number] [detail]
21.
show ip mroute [group-address | group-name] [source-address | source-name] [interface-type
interface-number] [summary] [count] [active kbps]
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Enables IP multicast routing.ip multicast-routing [distributed]
Step 3
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
OL-29890-01 147
Configuring PIM
Configuring Sparse Mode with Auto-RP
