Configuring Static Traffic Forwarding with SSM Mapping (CLI)
Use static traffic forwarding with SSM mapping to statically forward SSM traffic for certain groups.
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface type number
4.
ip igmp static-group group-address source ssm-map
5.
end
6.
show running-config
7.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Selects an interface on which to statically forward traffic for a multicast group
using SSM mapping, and enters interface configuration mode.
interface type number
Example:
Device(config)# interface
Step 3
The specified interface must be one of the following:
• A routed port—A physical port that has been configured as a Layer 3
port by entering the no switchport interface configuration command.
gigabitethernet 1/0/1
You will also need to enable IP PIM sparse-dense-mode on the interface,
and join the interface as a statically connected member to an IGMP static
group. For a configuration example, see Example: Interface Configuration
as a Routed Port, on page 83
• An SVI—A VLAN interface created by using the interface vlan vlan-id
global configuration command. You will also need to enable IP PIM
sparse-dense-mode on the VLAN, join the VLAN as a statically connected
member to an IGMP static group, and then enable IGMP snooping on
the VLAN, the IGMP static group, and physical interface. For a
configuration example, see Example: Interface Configuration as an SVI,
on page 83
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3650 Switches)
244 OL-29890-01
Configuring SSM
Configuring Source Specific Multicast Mapping
