Daikin VRV III User Manual

ED34-862 Specifications
FXKQ-MA 145
4
2. Specifications
Ceiling Mounted Cassette Corner Type
Note:
∗1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
∗4 Anechoic chamber conversion value, measured at a point 1 m in front of the unit and 1m downward. During actual operation, these values
are normally somewhat higher as a result of ambient conditions.
5 Refer to page 150 for Fan Motor Input.
Model FXKQ25MAVE FXKQ32MAVE FXKQ40MAVE FXKQ63MAVE
∗1 Cooling Capacity (19.5°CWB)
kcal/h 2,500 3,200 4,000 6,300
Btu/h 9,900 12,600 16,000 24,900
kW 2.9 3.7 4.7 7.3
∗2 Cooling Capacity (19.0°CWB) kW 2.8 3.6 4.5 7.1
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 215×1,110×710 215×1,110×710 215×1,110×710 215×1,310×710
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×11×1.75 2×11×1.75 2×11×1.75 3×11×1.75
Face Area m² 0.180 0.180 0.180 0.226
Fan
Model 3D12H1AN1V1 3D12H1AN1V1 3D12H1AP1V1 4D12H1AJ1V1
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 15×1 15×1 20×1 45×1
Air Flow Rate (H/L)
m³/min 11/9 11/9 13/10 18/15
cfm 388/318 388/318 459/353 635/530
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyethylene Foam Polyethylene Foam Polyethylene Foam Polyethylene Foam
Piping
Connections
Liquid Pipes mm
φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight (Mass) kg 31 31 31 34
∗4 Sound Level (H/L) (220V) dBA 38/33 38/33 40/34 42/37
Safety Devices
Fuse.
Thermal Fuse for Fan Motor.
Fuse.
Thermal Fuse for Fan Motor.
Fuse.
Thermal Fuse for Fan Motor.
Fuse.
Thermal Fuse for Fan Motor.
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Units R-410A PA Series R-410A PA Series R-410A PA Series R-410A PA Series
Decoration
Panels
(Option)
Model BYK45FJW1 BYK45FJW1 BYK45FJW1 BYK71FJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 70×1,240×800 70×1,240×800 70×1,240×800 70×1,440×800
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 8.5 8.5 8.5 9.5
Standard Accessories
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Clamp Metal.
Insulation for Fitting. Sealing
Pads. Clamps. Screws.
Washers. Positioning Jig for
Installation. Insulation for
Hanger Bracket. Air Outlet
Blocking Pad.
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Clamp Metal.
Insulation for Fitting. Sealing
Pads. Clamps. Screws.
Washers. Positioning Jig for
Installation. Insulation for
Hanger Bracket. Air Outlet
Blocking Pad.
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Clamp Metal.
Insulation for Fitting. Sealing
Pads. Clamps. Screws.
Washers. Positioning Jig for
Installation. Insulation for
Hanger Bracket. Air Outlet
Blocking Pad.
Operation Manual.
Installation Manual. Paper
Pattern for Installation. Drain
Hose. Clamp Metal.
Insulation for Fitting. Sealing
Pads. Clamps. Screws.
Washers. Positioning Jig for
Installation. Insulation for
Hanger Bracket. Air Outlet
Blocking Pad.
Drawing No. C : 3D038813A
( )( )( )( )
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
