Daikin VRV III User Manual

ED34-862 Specifications
FXDQ-PB / FXDQ-NB 165
5
2. Specifications
2.1 FXDQ-PB
Slim Ceiling Mounted Duct Type (VE: with Drain Pump, VET without Drain Pump)
Note:
★1 Indoor temp.: 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level difference: 0m.
★2 Indoor temp.: 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level difference: 0m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★4 External static pressure is changeable to set by the remote controller. This pressure means “High static pressure - Standard static pressure”.
(Factory setting is 10 Pa.)
★5 The operation sound levels are the conversion values in anechoic chamber. In practice, the sound tend to be larger than the specified values
due to ambient noise or reflections.
When the place of suction is changed to the bottom suction, the sound level will increase by approx. 5dBA.
★6 FXDQ20 / 25 / 32PBVE only.
7 Refer to page 176 for Fan Motor Input.
Model FXDQ20PBVE (T) FXDQ25PBVE (T) FXDQ32PBVE (T)
★1 Cooling Capacity (19.5°CWB)
kcal/h 2,000 2,500 3,200
Btu/h 7,800 9,900 12,600
kW 2.3 2.9 3.7
★2 Cooling Capacity (19.0°CWB) kW 2.2 2.8 3.6
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 200×700×620 200×700×620 200×700×620
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×12×1.5 2×12×1.5 3×12×1.5
Face Area m² 0.126 0.126 0.126
Fan
Model — — —
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 62×1 62×1 62×1
Air Flow Rate (HH/H/L) m³/min 8.0/7.2/6.4 8.0/7.2/6.4 8.0/7.2/6.4
★4 External Static Pressure Pa 30-10 30-10 30-10
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Foamed Polyethylene Foamed Polyethylene Foamed Polyethylene
Air Filter Removal / Washable / Mildew Proof Removal / Washable / Mildew Proof Removal / Washable / Mildew Proof
Piping
Connections
Liquid Pipes mm
φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm
φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
Machine Weight (Mass) kg 23 23 23
★5 Sound Pressure Level (HH/H/L) dBA 33/31/29 33/31/29 33/31/29
Safety Devices Fuse, Thermal Protector for Fan Motor Fuse, Thermal Protector for Fan Motor Fuse, Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual,
Installation Manual,
Drain Hose, Sealing Pads, Clamps,
Washers, Insulation for Fitting,
Clamp Metal, Washer Fixing Plate,
Screws for Duct Flanges, Air Filter,
(Product Quality Certificate
★6)
Operation Manual,
Installation Manual,
Drain Hose, Sealing Pads, Clamps,
Washers, Insulation for Fitting,
Clamp Metal, Washer Fixing Plate,
Screws for Duct Flanges, Air Filter,
(Product Quality Certificate ★6)
Operation Manual,
Installation Manual,
Drain Hose, Sealing Pads, Clamps,
Washers, Insulation for Fitting,
Clamp Metal, Washer Fixing Plate,
Screws for Duct Flanges, Air Filter,
(Product Quality Certificate ★6)
Drawing No. 3D060921A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
