Daikin VRV III User Manual

ED34-862 Specifications
FXFQ-P 49
2
2. Specifications
Ceiling Mounted Cassette (Round Flow) Type
Note:
∗
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
∗
4 Anechoic chamber conversion value, measured at a point 1.5 m downward from the unit centre. During actual operation, these values are
normally somewhat higher as a result of ambient conditions.
5 Refer to page 56 for Fan Motor Input.
Model FXFQ25PVE FXFQ32PVE FXFQ40PVE FXFQ50PVE
∗
1 Cooling Capacity (19.5°CWB)
kcal/h 2,500 3,200 4,000 5,000
Btu/h 9,900 12,600 16,000 19,800
kW 2.9 3.7 4.7 5.8
∗
2 Cooling Capacity (19.0°CWB) kW 2.8 3.6 4.5 5.6
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 246×840×840 246×840×840 246×840×840 246×840×840
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×6×1.2 2×6×1.2 2×6×1.2 2×6×1.2
Face Area m² 0.267 0.267 0.267 0.267
Fan
Model QTS48C15M QTS48C15M QTS48C15M QTS48C15M
Type Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 56×1 56×1 56×1 56×1
Air Flow Rate (HH/H/L)
m³/min 13/11.5/10 13/11.5/10 15/13/11 16/13.5/11
cfm 459/406/353 459/406/353 530/459/388 565/477/388
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form Polyurethane Form
Piping
Connections
Liquid Pipes mm
φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Mass (Weight) kg 19.5 19.5 19.5 19.5
∗
4 Sound Level (HH/H/L) (220-240V) dBA 30/28.5/27 30/28.5/27 31/29/27 32/29.5/27
Safety Devices Fuse Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A VRV PA Series R-410A VRV PA Series R-410A VRV PA Series R-410A VRV PA Series
Decoration
Panels
(Option)
Model BYCP125K-W1 BYCP125K-W1 BYCP125K-W1 BYCP125K-W1
Panel Color Fresh White Fresh White Fresh White Fresh White
Dimensions: (H×W×D) mm 50×950×950 50×950×950 50×950×950 50×950×950
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 5.5 5.5 5.5 5.5
Standard Accessories
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Drawing No. C : 3D060255
( )( )( )( )
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
