Daikin VRV III User Manual

ED34-862 Specifications
FXMQ-MA 297
8
2. Specifications
Ceiling Mounted Duct Type
Note:
∗1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗3 External static pressure is changeable to change over the connectors inside electrical box, this pressure means
"High static pressure-Standard".
∗4 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its colorimetric method (gravity method)
50% or more.
5 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
∗6 Anechoic chamber conversion value, measured at a point 1.5 m downward from the unit center. These values are normally somewhat higher
during actual operation as a result of ambient conditions.
7 Refer to page 301 for Fan Motor Input.
Model FXMQ200MAVE FXMQ250MAVE
∗1 Cooling Capacity (19.5°CWB)
kcal/h 19,800 24,800
Btu/h 78,500 98,300
kW 23.0 28.8
∗2 Cooling Capacity (19.0°CWB) kW 22.4 28.0
Casing Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 470×1,380×1,100 470×1,380×1,100
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×26×2.0 3×26×2.0
Face Area m² 0.68 0.68
Fan
Model D13/4G2DA1×2 D13/4G2DA1×2
Type Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 380×2 380×2
Air Flow Rate (H/L)
m³/min 58/50 72/62
cfm 2,047/1,765 2,542/2,189
External Static
Pressure 50Hz
Pa 221-132
∗3 270-191 ∗3
Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat for Cooling and Heating Microprocessor Thermostat for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber
Air Filter ∗4 ∗4
Piping
Connections
Liquid Pipes mm
φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ19.1(Brazing Connection) φ22.2 (Brazing Connection)
Drain Pipe mm PS1B PS1B
Machine Weight (Mass) kg 137 137
∗6 Sound Level (H/L) (220V) dBA 48/45 48/45
Safety Devices
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A PA Series R-410A PA Series
Standard Accessories
Operation Manual. Installation Manual. Sealing Pads.
Connection Pipes. Screws. Clamps.
Operation Manual. Installation Manual. Sealing Pads.
Connection Pipes. Screws. Clamps.
Drawing No. C : 3D038814A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
