Daikin VRV III User Manual

ED34-862 Specifications
FXLQ-MA / FXNQ-MA 361
11
2. Specifications
2.1 FXLQ-MA
Floor Standing Type
Note:
∗1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
∗4 Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m. During actual operation, these values
are normally somewhat higher as a result of ambient conditions.
5 Refer to page 373 for Fan Motor Input.
Model FXLQ20MAVE FXLQ25MAVE FXLQ32MAVE
∗1 Cooling Capacity (19.5°CWB)
kcal/h 2,000 2,500 3,200
Btu/h 7,800 9,900 12,600
kW 2.3 2.9 3.7
∗2 Cooling Capacity (19.0°CWB) kW 2.2 2.8 3.6
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 600×1,000×222 600×1,000×222 600×1,140×222
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.5 3×14×1.5 3×14×1.5
Face Area m² 0.159 0.159 0.200
Fan
Model D14B20 D14B20 2D14B13
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 15×1 15×1 25×1
Air Flow Rate (H/L)
m³/min 7/6 7/6 8/6
cfm 247/212 247/212 282/212
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber/ Urethane Foam Glass Fiber/ Urethane Foam Glass Fiber/ Urethane Foam
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm
φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm
φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride)
Machine Weight (Mass) kg 25 25 30
∗4 Sound Level (H/L) (220V) dBA 35/32 35/32 35/32
Safety Devices
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A PA Series R-410A PA Series R-410A PA Series
Standard Accessories
Operation Manual. Installation
Manual. Insulation for Fitting. Drain
Hose. Clamps. Screws. Washers.
Level Adjustment Screw.
Operation Manual. Installation
Manual. Insulation for Fitting. Drain
Hose. Clamps. Screws. Washers.
Level Adjustment Screw.
Operation Manual. Installation
Manual. Insulation for Fitting. Drain
Hose. Clamps. Screws. Washers.
Level Adjustment Screw.
Drawing No. C : 3D038816A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
