Daikin VRV III User Manual

ED34-862 Specifications
FXUQ-MA 383
12
2. Specifications
Ceiling Suspended Cassette Type
Notes:
★1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level difference: 0m.
★2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level difference: 0m.
3 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
★4 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These values are normally somewhat higher
during actual operation as a result of ambient conditions.
5 Refer to page 391 for Fan Motor Input.
Model
Indoor Unit FXUQ71MAV1 FXUQ100MAV1 FXUQ125MAV1
Connection Unit
BEVQ71MAVE BEVQ100MAVE BEVQ125MAVE
★1 Cooling Capacity (19.5°CWB)
kcal/h 7,100 10,000 12,500
Btu/h 28,300 39,600 49,500
kW 8.3 11.6 14.5
★2 Cooling Capacity (19.0°CWB) kW 8.0 11.2 14.0
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 165×895×895 230×895×895 230×895×895
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×6×1.5 3×8×1.5 3×8×1.5
Face Area m² 0.265 0.353 0.353
Fan
Model QTS48A10M QTS50B15M QTS50B15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 45×1 90×1 90×1
Air Flow Rate (H/L)
m³/min 19/14 29/21 32/23
cfm 671/494 1,024/741 1,130/812
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Piping
Connections
Liquid Pipes mm
φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm
φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
Machine Weight kg 25 31 31
★4 Sound Level (H/L) (230V) dBA 40/35 43/38 44/39
Safety Devices Thermal Protector for Fan Motor Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Standard Accessories
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Drawing No. C : 4D045395A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
