Daikin VRV III User Manual

Capacity Tables ED34-862
392 FXUQ-MA
7. Capacity Tables
7.1 Cooling Capacity
FXUQ-MA [50Hz]
Cooling capacity
Unit
Size
Outdoor
air temp.
°CDB
Indoor air temp.
14.0°CWB 16.0°CWB 18.0°CWB 19.0°CWB 20.0°CWB 22.0°CWB 24.0°CWB
20°CDB 23°CDB 26°CDB 27°CDB 28°CDB 30°CDB 32°CDB
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
71
10.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 10.5 6.3 12.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 10.4 6.2 14.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 10.3 6.2 16.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 10.1 6.1 18.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 10.0 6.0 20.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 9.8 5.9 21.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.6 6.2 9.8 5.9 23.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.4 6.2 9.6 5.8 25.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.3 6.1 9.5 5.7 27.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.2 6.0 9.4 5.7 29.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 9.0 5.9 9.2 5.7 31.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 8.9 5.8 9.1 5.6 33.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.0 8.5 6.0 8.7 5.8 8.9 5.6 35.0 5.4 4.8 6.4 5.2 7.5 5.8
8.0 6.0 8.4 6.0 8.6 5.7 8.8 5.5
37.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 5.9 8.3 6.0 8.5 5.8 8.7 5.4 39.0 5.4 4.8 6.4 5.2 7.5 5.8 8.0 6.1 8.1 5.9 8.3 5.6 8.5 5.4
100
10.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 14.7 8.5 12.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 14.5 8.4 14.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 14.4 8.3 16.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 14.2 8.2 18.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 14.0 8.1 20.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 13.8 8.0 21.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.4 8.4 13.7 7.9 23.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.2 8.2 13.5 7.8 25.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 13.0 8.1 13.3 7.7 27.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 12.8 8.0 13.1 7.7 29.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 12.6 7.9 12.9 7.6 31.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 12.4 7.9 12.7 7.6 33.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.9 8.3 12.2 7.8 12.5 7.6 35.0 7.6 6.6 9.0 7.1 10.5 8.0
11.2 8.2 11.8 8.3 12.1 7.7 12.3 7.4
37.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.6 8.3 11.9 7.7 12.2 7.3 39.0 7.6 6.6 9.0 7.1 10.5 8.0 11.2 8.2 11.4 8.2 11.7 7.6 12.0 7.3
125
10.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 18.4 10.8 12.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 18.2 10.7 14.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 18.0 10.5 16.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 17.7 10.4 18.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 17.5 10.2 20.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 17.2 10.1 21.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.8 10.7 17.1 10.0 23.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.5 10.5 16.9 9.9 25.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.3 10.4 16.6 9.9 27.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 16.1 10.2 16.4 9.8 29.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 15.8 10.1 16.2 9.7 31.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 15.6 10.0 15.9 9.6 33.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.9 10.6 15.3 9.9 15.7 9.6 35.0 9.5 8.0 11.3 9.0 13.1 9.9
14.0 10.4 14.8 10.5 15.1 9.9 15.4 9.4
37.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.5 10.5 14.9 9.8 15.2 9.4 39.0 9.5 8.0 11.3 9.0 13.1 9.9 14.0 10.4 14.3 10.2 14.6 9.6 15.0 9.3
TC Total capacity ; kW SHC Sensible heat capacity ; kW
Refer to Outdoor Unit Capacity Tables : on page 491~, 552~, for the actual performance data of each indoor
and outdoor unit combination.
