Daikin VRV III User Manual

ED34-862 Accessories
FXFQ-P 85
2
11.Accessories
Standard Accessories
FXFQ25~125P
3P161684-3B
Optional Accessories (For Unit)
Optional Accessories (For Controls) : Refer to P.645
Model
FXFQ25PVE FXFQ32PVE FXFQ40PVE FXFQ50PVE FXFQ63PVE FXFQ80PVE FXFQ100PVE FXFQ125PVE
Item
Decoration panel BYCP125K-W1
Sealing member of air discharge outlet KDBH55K160F
Panel spacer KDBP55H160FA
Filter
related
High efficiency
filter unit
65%
KAFP556H80 KAFP556H160
90%
KAFP557H80 KAFP557H160
Replacement
high efficiency
filter
65%
KAFP552H80 KAFP552H160
90%
KAFP553H80 KAFP553H160
Filter chamber KDDFP55H160
Replacement
long life filter
Non-
woven type
KAFP551K160
Ultra long-life filter KAFP55H160
Replacement ultra long life
filter
KAFP55H160H
Fresh air
intake kit
Chamber type
Without T-
joint pipe
and fan
KDDP55K160
With T-joint
pipe
without fan
KDDP55K160K
Direct installation type KDDP55X160
Branch duct chamber KDJP55H80 KDJP55H160
Chamber connection kit KKSJ55K160
Insulation kit for high humidity KDTP55K80 KDTP55K160
C:3D060297
Name (1) Drain hose (2) Metal clamp
(3) Washer for
hanger
bracket
(4) Clamp
(5) Paper pattern for
installation
(6) Screw (M4)
Quantity 1 pc. 1 pc. 8 pcs. 6 pcs. 1 pc. 4 pcs.
Shape
Also used as pack-
ing material
Name
(7) Washer
fixing plate
Insulation for
fitting
Sealing pad Installation guide
(Other)
• Installation
manual
• Operation
manual
Quantity 4 pcs. 1 each 1 each 1 pc. 1 pc. 1 pc.
Shape
(13) Small
For paper pattern
for installation
(8) for gas
pipe
(9) for liquid
pipe
(11) Medium-1
(12) Medium-2
(10) Large
(14)
(15)
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
