Installation Manual ED34-862
82 FXFQ-P
3P161684-3B
English 22
(2) Actuation
• The following table explains FORCED OFF and ON/OFF OPERATIONS in response to Input A.
(3) How to select FORCED OFF and ON/OFF OPERATION
• Turn the power on and then use the remote controller to select operation.
9-5 Centralized control
• For centralized control, it is necessary to designate the group No. For details, refer to the manual of each
optional controllers for centralized control.
10. INSTALLATION OF THE DECORATION PANEL
Caution:
With a wireless remote controller, field setting and test operation cannot be performed without attach-
ing the decoration panel.
<If performing a test run without attaching the decoration panel, read “11. FIELD SETTING” and “12. TEST
OPERATION” first.>
Refer to the installation manual attached to the decoration panel.
After installing the decoration panel, ensure that there is no space between the unit body and decoration panel.
11. FIELD SETTING
CAUTION
When performing field setting or test operation without attaching the decoration panel, do not
touch the drain pump. This may cause electric shock.
• Check that the outdoor unit has been wired properly.
Make sure the terminal box lids are closed on the indoor and outdoor units.
Field setting must be made from the remote controller and in accordance with installation conditions.
• Setting can be made by changing the “Mode No.”, “FIRST CODE NO.” and “SECOND CODE NO.”.
• For setting procedures and instructions, see “Field settings” provided with the remote controller.
11-1 Setting ceiling height
• Select the SECOND CODE NO. that corresponds to the ceiling height “Table 4”.
(SECOND CODE NO. is factory set to “01”.)
Table 4
Note:
1. “Mode No.” setting is done in a batch for the group. To make or confirm settings for an individual unit, set
the internal mode number in parentheses.
2. The figure of the ceiling height is for the all round outlet. For the settings for four-direction (part of corner
closed off), three-direction and two-direction outlets, see the installation manual and technical guide sup-
plied with the separately sold closure material kit.
FORCED OFF ON/OFF OPERATION
Input “ON” stops operation (impossible by remote controllers.) Input OFF → ON turns ON unit.
Input OFF enables control by remote controller. Input ON → OFF turns OFF unit.
FXFQ - PVE
Mode No.
Note) 1
FIRST
CODE NO.
SECOND
CODE NO.
25 · 32 · 40 · 50
· 63 · 80 type
100 · 125 type
Ceiling
height (m)
Standard · All
round outlet
≤ 2.7 ≤ 3.2
13 (23) 0
01
High ceiling 1 2.7 - 3 3.2 - 3.6 02
High ceiling 2 3 - 3.5 3.6 - 4.2 03
