Daikin VRV III User Manual

ED34-862 Installation Manual
FXFQ-P 75
2
3P161684-3B
15 English
CAUTION
Drain piping connections
Do not connect the drain piping directly to sewage pipes that smell of ammonia. The ammonia in the sew-
age might enter the indoor unit through the drain pipes and corrode the heat exchanger.
8. ELECTRIC WIRING WORK
8-1 General instructions
• All field supplied parts and materials and electric works must conform to local codes.
• Use copper wire only.
• For electric wiring work, refer to also “WIRING DIAGRAM” attached to the unit body.
• For remote controller wiring details, refer to the installation manual attached to the remote controller.
• All wiring must be performed by an authorized electrician.
• A circuit breaker capable of shutting down power supply to the entire system must be installed.
• Refer to the installation manual attached to the outdoor unit for the size of power supply electric wire con-
nected to the outdoor unit, the capacity of the circuit breaker and switch, and wiring instructions.
• Be sure to ground the air conditioner.
• Do not connect the ground wire to gas pipes, plumbing pipes, lightning rods, or telephone ground wires.
• Gas pipes: might cause explosions or fire if gas leaks.
• Plumbing: no grounding effect if hard vinyl piping is used.
• Telephone ground wires or lightning rods: might cause abnormally high electric potential in the ground
during lighting storms.
8-2 Electrical characteristics
MCA: Min. Circuit Amps (A) MFA: Max. Fuse Amps (A)
kW: Fan Motor Rated Output (kW) FLA: Full Load Amps (A)
Units
Power
supply
Fan motor
Model Hz Volts Voltage range MCA MFA kW FLA
FXFQ25PVE
50 220-240
Max. 264
Min. 198
0.3 15 0.056 0.2
FXFQ32PVE 0.3 15 0.056 0.2
FXFQ40PVE 0.3 15 0.056 0.2
FXFQ50PVE 0.3 15 0.056 0.2
FXFQ63PVE 0.4 15 0.056 0.3
FXFQ80PVE 0.5 15 0.056 0.4
FXFQ100PVE 1.3 15 0.120 1.0
FXFQ125PVE 1.5 15 0.120 1.2
FXFQ25PVE
60 220
Max. 242
Min. 198
0.3 15 0.056 0.2
FXFQ32PVE 0.3 15 0.056 0.2
FXFQ40PVE 0.3 15 0.056 0.2
FXFQ50PVE 0.3 15 0.056 0.2
FXFQ63PVE 0.4 15 0.056 0.3
FXFQ80PVE 0.5 15 0.056 0.4
FXFQ100PVE 1.3 15 0.120 1.0
FXFQ125PVE 1.5 15 0.120 1.2
