Daikin VRV III User Manual

Capacity Tables ED34-862
374 FXLQ-MA / FXNQ-MA
7. Capacity Tables
7.1 Cooling Capacity
FXLQ-MA / FXNQ-MA [50Hz]
Cooling capacity Cooling capacity
Unit
Size
Outdoor
air temp.
°CDB
Indoor air temp.
Unit
Size
Outdoor air temp.
°CDB
Indoor air temp.
14.0°CWB 16.0°CWB 18.0°CWB 19.0°CWB 20.0°CWB 22.0°CWB 24.0°CWB 14.0°CWB 16.0°CWB 18.0°CWB 19.0°CWB 20.0°CWB 22.0°CWB 24.0°CWB
20°CDB 23°CDB 26°CDB 27°CDB 28°CDB 30°CDB 32°CDB 20°CDB 23°CDB 26°CDB 27°CDB 28°CDB 30°CDB 32°CDB
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
20
10.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.9 1.8
40
10.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.9 3.3
12.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.9 1.7 12.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.8 3.3 14.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.8 1.7 14.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.8 3.2 16.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.8 1.7 16.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.7 3.2 18.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.7 1.7 18.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.6 3.1 20.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.7 1.6 20.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.5 3.1 21.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.7 1.6 21.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.4 3.3 5.5 3.1 23.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.8 2.6 1.6 23.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.3 3.2 5.4 3.0 25.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.6 1.7 2.6 1.6 25.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.2 3.2 5.3 3.0 27.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.5 1.7 2.6 1.6 27.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.2 3.1 5.3 3.0 29.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.5 1.7 2.5 1.6 29.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.1 3.1 5.2 3.0 31.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.4 1.7 2.5 1.6 31.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 5.0 3.1 5.1 2.9 33.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.8 2.4 1.7 2.5 1.6 33.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.8 3.2 4.9 3.0 5.0 2.9 35.0 1.5 1.3 1.8 1.5 2.1 1.7
2.2 1.7 2.3 1.7 2.4 1.6 2.4 1.5 35.0 3.0 2.5 3.6 2.7 4.2 3.1 4.53.14.73.24.93.15.02.9
37.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.3 1.7 2.3 1.6 2.4 1.6 37.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.1 4.7 3.2 4.8 3.0 4.9 2.8 39.0 1.5 1.3 1.8 1.5 2.1 1.7 2.2 1.7 2.2 1.7 2.3 1.6 2.3 1.5 39.0 3.0 2.5 3.6 2.7 4.2 3.1 4.5 3.2 4.6 3.1 4.7 3.0 4.8 2.8
25
10.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.7 2.1
50
10.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 7.4 4.1
12.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.6 2.1 12.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 7.3 4.1 14.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.6 2.1 14.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 7.2 4.0 16.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.5 2.1 16.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 7.1 4.0 18.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.5 2.0 18.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 7.0 3.9 20.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.4 2.0 20.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 6.9 3.9 21.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.4 2.1 3.4 2.0 21.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.7 4.1 6.8 3.8 23.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.3 2.1 3.4 2.0 23.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.6 4.0 6.7 3.8 25.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.3 2.1 3.3 2.0 25.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.5 4.0 6.6 3.7 27.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.2 2.1 3.3 1.9 27.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.4 3.9 6.6 3.7 29.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.2 2.0 3.2 1.9 29.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.3 3.9 6.5 3.7 31.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.1 2.0 3.2 1.9 31.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.2 3.8 6.4 3.7 33.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 3.0 2.1 3.1 2.0 3.1 1.9 33.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 6.0 4.0 6.1 3.8 6.3 3.6 35.0 1.9 1.6 2.3 1.8 2.6 2.0
2.8 2.1 3.0 2.1 3.0 2.0 3.1 1.9 35.0 3.8 3.0 4.5 3.4 5.2 3.8 5.63.95.94.06.03.86.23.6
37.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 2.9 2.0 3.0 2.0 3.0 1.9 37.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 5.8 3.9 5.9 3.7 6.1 3.6 39.0 1.9 1.6 2.3 1.8 2.6 2.0 2.8 2.1 2.9 2.0 2.9 2.0 3.0 1.9 39.0 3.8 3.0 4.5 3.4 5.2 3.8 5.6 3.9 5.7 3.9 5.8 3.7 6.0 3.5
32
10.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.7 2.6
63
10.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 9.3 5.0
12.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.7 2.6 12.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 9.2 5.0 14.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.6 2.6 14.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 9.1 4.9 16.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.6 2.5 16.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 9.0 4.8 18.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.5 2.5 18.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 8.8 4.8 20.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.4 2.5 20.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 8.7 4.7 21.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.3 2.6 4.4 2.5 21.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.5 5.1 8.7 4.7 23.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.2 2.6 4.3 2.4 23.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.4 5.0 8.5 4.6 25.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.2 2.6 4.3 2.4 25.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.3 5.0 8.4 4.5 27.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.1 2.5 4.2 2.4 27.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.1 4.9 8.3 4.5 29.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.1 2.5 4.2 2.4 29.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 8.0 4.8 8.2 4.5 31.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 4.0 2.5 4.1 2.4 31.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 7.9 4.7 8.1 4.4 33.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.8 2.6 3.9 2.4 4.0 2.3 33.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.6 5.0 7.8 4.7 7.9 4.4 35.0 2.4 2.1 2.9 2.2 3.4 2.5
3.6 2.5 3.8 2.5 3.9 2.4 4.0 2.3 35.0 4.8 3.7 5.7 4.2 6.6 4.8 7.14.97.54.97.74.77.84.3
37.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.5 3.7 2.5 3.8 2.4 3.9 2.3 37.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.4 4.9 7.5 4.6 7.7 4.2 39.0 2.4 2.1 2.9 2.2 3.4 2.5 3.6 2.6 3.7 2.5 3.8 2.4 3.8 2.3 39.0 4.8 3.7 5.7 4.2 6.6 4.8 7.1 4.9 7.2 4.8 7.4 4.6 7.6 4.2
TC Total capacity ; kW SHC Sensible heat capacity ; kW
Refer to Outdoor Unit Capacity Tables : on page 491~, 552~, for the actual performance data of each indoor
and outdoor unit combination.
