Daikin VRV III User Manual

ED34-862 Installation
FXSQ-M 223
6
10.Installation
Center of Gravity
Service Space
Note:
Above figure means minimum value. Please keep these value at least.
Bolt Pitch
· For standard installation (air inlet on the bottom side),
choose one of the below two means of installation.
Note: For other than standard installation, contact your Daikin dealer for details.
Drain Pump Kit
Unit (mm)
Unit (mm)
Indoor unit Drain pump kit
FXSQ-M Standard (Equipped with indoor unit)
C : 4D036946F
Maintenance
space
For installation in high places
300 mm
or more
2500 mm
or more
Drain pipe
Liquid pipe
Power supply
wiring port
Maintenance drain hose
Transmission
wiring port
Gas pipe
3P086156-7D
B
A
Pipe
Suspension
bolt pitch
Indoor unit
800
Suspension bolt (× 4)
145
Suspension bolt pitch
630
Model
FXSQ20 · 25 · 32MVE
FXSQ40 · 50MVE
FXSQ63MVE
FXSQ80 · 100 · 125MVE
(Unit : mm)
A
550
700
1000
1400
B
600
750
1050
1450
3P086156-7D
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
