Daikin VRV III User Manual

Capacity Tables ED34-862
178 FXDQ-PB / FXDQ-NB
7.2 FXDQ-NB
[50Hz]
Cooling capacity
Unit
Size
Outdoor
air temp.
°CDB
Indoor air temp.
14.0°CWB 16.0°CWB 18.0°CWB 19.0°CWB 20.0°CWB 22.0°CWB 24.0°CWB
20°CDB 23°CDB 26°CDB 27°CDB 28°CDB 30°CDB 32°CDB
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
40
10.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.9 3.5 12.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.8 3.5 14.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.8 3.5 16.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.7 3.5 18.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.6 3.4 20.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.5 3.4 21.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.4 3.3 5.5 3.4 23.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.3 3.3 5.4 3.3 25.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.2 3.3 5.3 3.3 27.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.2 3.2 5.3 3.3 29.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.1 3.2 5.2 3.3 31.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 5.0 3.2 5.1 3.2 33.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.8 3.2 4.9 3.2 5.0 3.2 35.0 3.0 2.5 3.6 2.8 4.2 3.3
4.5 3.3 4.7 3.2 4.9 3.1 5.0 3.2
37.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.7 3.2 4.8 3.1 4.9 3.1 39.0 3.0 2.5 3.6 2.8 4.2 3.3 4.5 3.3 4.6 3.2 4.7 3.1 4.8 3.1
50
10.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 7.4 4.1 12.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 7.3 4.1 14.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 7.2 4.1 16.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 7.1 4.0 18.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 7.0 4.0 20.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 6.9 4.0 21.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.7 4.2 6.8 4.0 23.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.6 4.2 6.7 3.9 25.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.5 4.1 6.6 3.9 27.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.4 4.1 6.6 3.9 29.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.3 4.0 6.5 3.8 31.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.2 4.0 6.4 3.8 33.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 6.0 4.0 6.1 4.0 6.3 3.8 35.0 3.8 3.1 4.5 3.5 5.2 3.9
5.6 4.0 5.9 4.0 6.0 3.9 6.2 3.7
37.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 5.8 4.0 5.9 3.9 6.1 3.7 39.0 3.8 3.1 4.5 3.5 5.2 3.9 5.6 4.0 5.7 3.9 5.8 3.9 6.0 3.7
63
10.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 9.3 5.7 12.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 9.2 5.6 14.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 9.1 5.5 16.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 9.0 5.4 18.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 8.8 5.4 20.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 8.7 5.3 21.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.5 5.1 8.7 5.3 23.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.4 5.1 8.5 5.2 25.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.3 5.0 8.4 5.1 27.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.1 5.0 8.3 5.1 29.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 8.0 4.9 8.2 5.0 31.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 7.9 4.9 8.1 4.9 33.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.6 4.9 7.8 4.8 7.9 4.9 35.0 4.8 3.8 5.7 4.3 6.6 4.8
7.1 4.9 7.5 4.8 7.7 4.8 7.8 4.8
37.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.4 4.8 7.5 4.7 7.7 4.8 39.0 4.8 3.8 5.7 4.3 6.6 4.8 7.1 4.9 7.2 4.7 7.4 4.7 7.6 4.7
TC Total capacity ; kW SHC Sensible heat capacity ; kW
Refer to Outdoor Unit Capacity Tables : on page 491~, 552~, for the actual performance data of each indoor
and outdoor unit combination.
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
