Daikin VRV III User Manual

ED34-862 Sound Levels
FXSQ-M 221
6
9. Sound Levels
Overall
 Ceiling Mounted Built-In Type
Note:
1. The operating conditions are assumed to be standard
(JIS conditions).
2. These operating values were obtained in a dead
room (conversion values).
Sound level will vary depending on a range of factors
such as the construction (acoustic absorption
coefficient) of the particular room in which the
equipments installed.
dBA
Model
220V, 50Hz 240V, 50Hz
HLHL
FXSQ20M
FXSQ25M
37 32 39 34
FXSQ32M
FXSQ40M
38 32 40 34
FXSQ50M 41 36 43 38
FXSQ63M 42 35 44 37
FXSQ80M
FXSQ100M
43 37 45 39
FXSQ125M 46 41 48 43
4D036937
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
