1. Model Names of Indoor/Outdoor Units
Indoor Units
Note: FXDQ has following 2 series, as shown below.
FXDQ-PBVET, NBVET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-PBVE, NBVE: with Drain Pump
BEV unit is required for FXUQ only.
MA:
RoHS Directive models; Specifications, dimensions and other functions are not changed compared with M type.
Outdoor Units
Normal Series (Space Saving Series)
High COP Series (Energy Saving Series)
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Round Flow)
FXFQ — 25P 32P 40P 50P 63P — 80P 100P 125P ——
VE
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M — 80M — 125M ——
Ceiling Mounted
Cassette Corner
Type
FXKQ — 25MA 32MA 40MA — 63MA ——————
Slim Ceiling Mounted
Duct Type
FXDQ-
PBVE
20PB 25PB 32PB —————————
FXDQ-
PBVET
20PB 25PB 32PB —————————
FXDQ-
NBVE
——— 40NB 50NB 63NB ——————
FXDQ-
NBVET
——— 40NB 50NB 63NB ——————
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M — 80M 100M 125M ——
Ceiling Mounted Duct
Type (Middle and
high static pressure)
FXMQ 20P 25P 32P 40P 50P 63P — 80P 100P 125P ——
Ceiling Mounted
Duct Type
FXMQ —————————— 200MA 250MA
Ceiling Suspended
Type
FXHQ — — 32MA —— 63MA —— 100MA ———
Wall Mounted Type
FXAQ 20MA 25MA 32MA 40MA 50MA 63MA ——————
Floor Standing Type
FXLQ 20MA 25MA 32MA 40MA 50MA 63MA ——————
Concealed Floor
Standing Type
FXNQ 20MA 25MA 32MA 40MA 50MA 63MA ——————
Ceiling Suspended
Cassette Type
FXUQ —————— 71MA — 100MA 125MA —— V1
Connection Unit for
FXUQ
BEVQ —————— 71MA — 100MA 125MA —— VE
Series Model Name Power Supply
Cooling Only RXQ
5PA 8PA 10PA 12PA 14PA 16PA 18PA 20PA 22PA
Y124PA 26PA 28PA 30PA 32PA 34PA 36PA 38PA 40PA
42PA 44PA 46PA 48PA 50PA 52PA 54PA
Series Model Name Power Supply
Cooling Only RXQ
16PAH 18PAH 24PAH 26PAH 28PAH 30PAH 32PAH 34PAH 36PAH
Y1
38PAH 40PAH 42PAH 44PAH 46PAH 48PAH 50PAH
VE: 1
φ, 220~240V, 50Hz
1φ, 220V, 60Hz
V1: 1φ, 220~240V, 50Hz Y1: 3φ, 380~415V, 50Hz
