Features ED34-862
382 FXUQ-MA
1. Features
Flexibility in installation location
Because the installation location, air flow direction and air flow rate can be selected according to the shape, lighting,
and interior design of a room, the Ceiling Suspended Cassette Type air conditioner will create a comfortable
environment throughout the room. This is a completely new air conditioning system that produces the comfort level of
a four-way air flow, ceiling-mounted cassette type air conditioner with the ease of a ceiling-suspended unit.
Development back ground of FXUQ-MA
Ceiling Mounted Cassette Type
Ceiling Mounted Cassette Type
Ceiling Suspended Cassette Type
Ceiling Suspended Cassette Type
Ceiling Suspended Type
Ceiling Suspended Type
Suitable for where there is
no ceiling space
Realized comfort and design flexibility at the same time for exposed installation.
Better air distribution and
easy installation
Take the both advantage in this product
•Daikin unique cassette
•Low Silhouette design:
71 Type -
165 mm thickness
(Current Multi Flow Cassette:338mm)
Flexible Design Easy Installation
•Flexible piping installation
(3 directions)
•Ceiling space not required
•Aesthetically pleasing design
•High ceiling up 3.5m
•Flexible air distribution by control of
direction and volume
Easy Maintenance
•Long life filter (standard accessories)
•Drain pump(standard accessories)
<Variable discharge direction and air volume>
Air volume is
controlled using
internal vanes
Standard
Standard
(100%)
(100%)
Regulated
Regulated
(70%)
(70%)
Air flow rate
Все каталоги и инструкции здесь: http://splitoff.ru/tehn-doc.html

Daikin VRV III Specifications

General

Type	VRV (Variable Refrigerant Volume)
Refrigerant	R410A
Energy Efficiency	High
Control	Centralized control systems, individual zone control
Operating Temperature Range (Cooling)	-5°C to 46°C
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted, Floor Standing, Ducted
Power Supply	380-415V, 50/60Hz, 3-Phase (depending on model)
