Parameter 6-63 Terminal X30/8 Bus Control
Table 434: Parameter 6-63 Terminal X30/8 Bus Control
6-63 Terminal X30/8 Bus Control
Parameter type: Range, 0 - 100%
Change during operation: True
Holds the level of output X30/8 if controlled by bus.
Parameter 6-64 Terminal X30/8 Output Timeout Preset
Table 435: Parameter 6-64 Terminal X30/8 Output Timeout Preset
6-64 Terminal X30/8 Output Timeout Preset
Parameter type: Range, 0 - 100%
Change during operation: True
Holds the preset level of output X30/8. If a timeout function is selected in parameter 6-60 Terminal X30/8 Output, the output is preset
to this level if a fieldbus timeout occurs.
5.7.8 6-7* Analog Output 3 MCB 113
Parameters for configuring the scaling and limits for analog output 3, terminals X45/1, and X45/2. Analog outputs are current out-
puts: 0/4–20 mA. Resolution on analog output is 11 bit.
Parameter 6-70 Terminal X45/1 Output
Table 436: Parameter 6-70 Terminal X45/1 Output
6-70 Terminal X45/1 Output
Default value: [0] No operation
Change during operation: True
Select the function of terminal X45/1 as an analog current output.
Indicates no signal on the analog output.
0 Hz = 0 mA; 100 Hz = 20 mA.
Parameter 3-00 Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA.
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 20 mA.
Example: Inverter normal current (11 kW) is 24 A. 160 %=38.4 A. Motor normal current is 22 A, the
readout is 11.46 mA.
20mA × 22A
38 . 4îš‹A
îš‹ = îš‹11 . 46îš‹mA
When the normal motor current is equal to 20 mA, the output setting of parameter 6-52 Terminal
42 Output Max Scale is:
AU275636650261en-000101 / 130R0334246 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
