6-22 Removal and Replacement
Output Hopper
Removal Procedure
1. Turn off the printer and unplug the power cord.
2. Remove the ribbon cartridge and cleaning roller.
3. Remove the
Main Enclosure (page 6-15).
4. Press up on the hopper retaining latches (one on either side of the hopper)
and pull the hopper straight out to remove it. You will feel a little resistance
until the upper retaining hooks release from the transport chassis.
Replacement Note
When reinstalling the hopper, make sure both lower retaining latches snap into
position.
