CP80 and CP80 Plus Service Manual 3-3
Print Engine Routine Maintenance Procedure
The entire routine maintenance procedure should be completed each time the
printer is serviced. This will help extend the life of the printer.
 Refer to chapter 6 of this manual for removal and replacement procedures.
CAUTION: Do not spray or pour cleaner directly on or into any electrical
device.
Clean the Interior of the Printer
1. Unplug the printer.
2. Remove the printer enclosures.
3. Remove the chassis from the base enclosure.
4. Using canned compressed air:
• Blow out any debris near the sensors
• Blow out any dust from the control board and other surfaces of the base.
• Blow out any dust and debris from the underside of the chassis. Make
sure to include the cam sensor.
5. If the grease on the platen roller shaft has accumulated dirt and debris, wipe
off the grease with a dry cloth, and re-grease the surfaces with Molykote DX
grease.
